When designing the Explorer, OSSA engineers and designers were based on the following approach: create a bike that was easier to reach the most difficult places. Its extreme lightness and trials qualities, combined with its enhanced ergonomics, make it possible to enjoy both tours real quiet as trial areas.

For 2014, the Explorer receives multiple internal and external improvements. The engine has been thoroughly revised to improve reliability and further refine its operation, while in the cycle have polished practical details that make the experience even better to ride an Explorer.

OSSA Explorer 2014. Reinventing the trial-trip.

Engine news
New engine 2014 with ball bearing in the crankshaft
New reinforced gearbox
New easy start system without maintenance
Ecu new location in the interior of the bike
New wiring
Cycle news
New location for the contact key
Rear fender with new material more rigid
New casting footrests
Frame and subframe in black
Plastics in black with new 2014 graphics
New chain tensioner spring

Specification

Ossa Explorer Engine

Capacity

272,2 cc

Type

2T monocylinder Inverted
with reed rox admission

Cooling System

Liquid

Bore x Stroke

76×60 mm

Fuel Supply

Electronic Injection by
KOKUSAN

Ignition

EFI Kokusan assisted by a
Lithium battery

Clutch

Multidisc hydraulic wet clutch

Gear box

6 speed

Transmission

Transmission by gears, final
transmission by chain.

Engine lubrication

Mixture 100% synthetic
oil lubrication 0.9%

Gear and clutch lubrication

Oil 450 cc. of Gear Extreme
type 75 W Mineral oil.



OSSA Explorer Frame

Type

TTubular Cr-Mo / Aluminium
with patented Fuel Tank by OSSA

Front suspension

Marzocchi Hydraulic Fork 40 mm. Extension and compression adjustable

Rear Suspension

Shock Absorber Hydraulic Monoshock Extension and spring load adjustable

Front Break

185 mm disc with 2 piston
caliper

Rear Break

160 mm disc with 2 piston
caliper

Front Wheel

1.6 x 21 80/100-21

Rear Wheel

2.15 x 18 120/100-18

Engine Protector

Made in AA7075 T6

Kick Start

Forged aluminum

Gear and brake pedal

Levers with retractable tips



Ossa Explorer Weight and dimensions

Wheelbase

1.328 mm

Seat height

820 mm

Ground Clearance

340 mm

Tank capacity

7,6 liters

Dry weight

74 Kg
